25BY46L Stepping Motor

Product Description:

Household appliances、 Sanitary Product Market、 Industrial Solutions、 OA&FA、 Office equipment、 Valve Market、Electronic expansion valve


Product Detail

Product Detail

 Performance Parameter

model stepping angle drive method circuit voltage current resistance insulation resistance insulation&voltage resistance insulation level
25BY46L-39 24(15°/Step) 2-2 PHASE UNIPOLAR CONST.VOLT 12[V] 50[Ω] 100M[Ω]MIN AC 500[V]1[min] CLASS E
25BY46L-38 24(15°/Step) 2-2 PHASE BIPOLAR CONST.VOLT 24[V] 600mA 10[Ω] 100M[Ω]MIN AC 500[V]1[min] CLASS E

  Dimension

 Performance Curves

Automated Production Line

08
06
07

Measurement Center

B41A4405
B41A4359
B41A4374

Laboratory

B41A4411
B41A4427
B41A4431
B41A4415
B41A4422
B41A4413

Certificates

CASC32

CASC

CEPREI13

CEPREI

CQC43

CQC

VDE434

VDE

UL423

UL
