Naming Convention
Product Introduction
- Operates at 24V, ≤5W power, with ≤200mA free-load current and 19V starting voltage.
- Delivers ≥1.5 kgf·cm running torque, ≤0.2 kgf·cm return torque, and ≤75K coil temperature rise.
- Insulation grade F, ≥100 MΩ insulation resistance, and AC1500V withstand voltage ensure long-lasting reliability.
Product Introduction
- Operates at AC230V (50/60Hz) with ≤6W power and ≤30mA current.
- Delivers ≥0.07 N·m pull-out torque and ≥0.065 N·m starting torque.
- Maintains ≤50K temperature rise, ≤50 dB noise level, and ≥100 MΩ insulation resistance.
Product Application
- Valve control
Product Introduction
- Operates at AC24V (50/60Hz) with ≤5W power and ≤400mA current.
- Delivers ≥0.144 N·m pull-out torque and ≥0.12 N·m starting torque.
- Maintains ≤50K temperature rise, ≤50 dB noise level, and ≥100 MΩ insulation resistance.
Product Application
- Valve control
Product Introduction
- Electrical Performance: Rated 12V, no-load current ≤0.1A, operating current ≤0.15A, stall current ≤0.5A.
- Mechanical Features: Single travel time 30s±20%, rack travel 100±2mm, pushing force >70N, overload >120N.
- Durability & Noise: Product lifecycle ≥5000 times, noise ≤48dB (30cm), overload protection ≥100N for safety.
Product Application
- Smart appliances
Product Introduction
- Operates at 220V, 50Hz, with a rated power of ≤9W and current consumption of ≤50mA.
- Delivers a precise flow rate of 45±2.5mL/min, ensuring consistent dosing performance with ≥1m lift.
- Designed with Class E insulation, maintaining low noise levels of ≤50dB for quiet operation.
Product Application
- Washing machine
