Hybrid Stepper Motor 20BYG

█ Product Introduction

Model:20BYG
20 series hybrid screw-lead stepper motor is the smallest hybrid screw-lead stepping motor in the product, which provides an effective solution for engineers to realize precision transmission in a limited space. The maximum thrust can reach 45N.
█ Application
Industry: Industrial Control
Sports health: medical equipment

█ Optional parts

Planetary gearbox, lead screw, hollow shaft, drive

Warm reminder:
The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact marketing@leiligroup.com.

Availability:

Quantity:



Inquiry PDF Export

Application:
Industry, Sports health
Dimension Diameter（Hybrid Stepper Motor）:
20
Rated Current（A）Hybrid Stepper Motor:
0.1-0.5
Rated Voltage（V）Hybrid Stepper Motor:
6-10
Holding Torque（mN.m）Hybrid Stepper Motor:
0-100, 101-200, 201-300, 300+
Motion Frequency（pps）Hybrid Stepper Motor:
0-1500, 1500-3000, 3000-4500, 4500+

Product Description

Product performance

motor model	Phase voltage	Phase current	Phase resistance	Phase inductance	Motor weight	Number of leads	Motor length
motor model	(VDC)	(A)	(Ω)	(mH)	(g)	Number of leads	(mm)
8-2105	2.5	0.5	5.1	1.5	51	4	37.2
8-2205	4.4	0.5	8.8	2.7	74	4	38.1

Optional lead screw and step

Screw diameter	Screw diameter	Lead	Lead	Leader code	stroke@ 1.8 °
(inch)	(mm)	(inch)	(mm)	Leader code	(mm)*
0.138	3.5	0.0118	0.3	AF	0.0015
0.138	3.5	0.024	0.6096	AA	0.003
0.138	3.5	0.0394	1	AB	0.005
0.138	3.5	0.048	1.2192	B	0.0061
0.138	3.5	0.0787	2	G	0.01
0.138	3.5	0.1575	4	M	0.02
0.138	3.5	0.315	8	T	0.04
