82zy Treadmill Motor

█ Product Introduction

Model:82zy
A brushed DC motor is a DC motor, assembling main magnetic pole and brush on the stator and assembling the winding coil and commutator assembled on the rotor. The electric energy from the dc power supply enters the armature winding through the brush and commutator, generating the armature current. The magnetic field generated by the armature current interacts with the main magnetic field to generate the electromagnetic torque, making the motor rotate to drive the load.
█ Application
Industrial: Industrial Controls
Exercise & Health: Treadmill

█ Optional parts

Warm reminder:
The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact marketing@leiligroup.com.

Availability:

Quantity:



Inquiry PDF Export

Application:
Industry, Sports health
Rated Voltage（V）DC Brush Motor:
120+
No-load Speed（r/min）DC Brush Motor:
0-1000, 1000-3000, 3000-10000, More Than 10000
No-load Current（A）DC Brush Motor:
0-0.1, 0.1-0.2, 0.2-0.3, More Than 0.3
Locked-rotor Current（A）DC Brush Motor:
5-10
Output Power （W）DC Brush Motor:
10+

Product Description

Performance parameter

model	vol (V)	kv (V)	no-load (A)	output power (W)	current (A)	rated torque (N.m)	efficiency	insulation level
82ZY1-1	130	16.5	1.5	1492	11	1.55	82.24%	N
82ZY2-1	130	16.2	1.5	1939	15	2.2	82.36%	N
