Air conditioning drain valve DF3-1

█ Product Introduction

Suitable for air conditioning outdoor unit drainage, sweeping robot drainage
█ Application

Household appliances: air conditioner, robot vacuum cleaner

█ Optional parts

Warm reminder:
The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact marketing@leiligroup.com.

Availability:

Quantity:


Inquiry PDF Export

Application:
Home appliance
Dimension Diameter（Geared Stepper Motor）:
20
Step Angle(°) Geared Stepper Motor:
3.75
Rated Voltage（DCV）Geared Stepper Motor:
5
Resistance(Ω) Geared Stepper Motor:
0-100
Operating Frequency (Geared Stepper Motor):
100
Pull in Torque(mN.m) Geared Stepper Motor:
1-100

Product Description

Performance Parameter

Resistance(Ω)/ Phase(at25°℃)	Endplay	ReductionRatio	Pull-inTorque (mN·m)	DetentTorque (mN·m)	Max. FreeloadPull-inFrequency (PPS)	Max. FreeloadPull-outFrequency (PPS)	★InsulationResisstance （DC500V) (MΩ)	peratureTemRise (K）(125pps)	Noise dB(A)
120	7.5°/42.5	1/42.5	≥294	≥147	≥200	≥ 200	≥100★	≤ 60	≤ 40
