Hybrid Stepper Motor 35BYG

█ Product introduction

Model: 35BYG
Hybrid stepper motor, also known as HB stepper motor, combines the characteristics of variable reluctance stepper motor and permanent magnet stepper motor. It controls the Angle movement by controlling the input pulse, so as to achieve accurate positioning.
█ Product Application
Industries: Display, OA financial equipment, weighing instrument, stage lighting

█ Optional parts

Warm reminder:
The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact marketing@leiligroup.com.

Availability:

Quantity:



Inquiry PDF Export

Application:
Industry
Dimension Diameter（Hybrid Stepper Motor）:
35
Rated Current（A）Hybrid Stepper Motor:
0.5-1
Rated Voltage（V）Hybrid Stepper Motor:
6-10
Holding Torque（mN.m）Hybrid Stepper Motor:
101-200, 201-300, 300+
Motion Frequency（pps）Hybrid Stepper Motor:
4500+

Product Description

Product parameter

motor model	Step angle	Phase voltage	Current	Resistance	Inductance	Holding torque	Running torque	Starting frequency	Exercise frequency	Weight	Total height
motor model	(°)	(VDC)	(A)	(Ω)	(mH)	(mN.m)	(mN.m)	(PPS)	(PPS)	(Kg)	（mm）
35BYG7-1	1.8	6.5	0.5	13	15	≥80	≥43	2700	5000	0.1	20
