116ZY Treadmill Motor

Product Introduction
Model:116ZY
A brushed DC motor is a DC motor, assembling main magnetic pole and brush on the stator and assembling the winding coil and commutator assembled on the rotor. The electric energy from the dc power supply enters the armature winding through the brush and commutator, generating the armature current. The magnetic field generated by the armature current interacts with the main magnetic field to generate the electromagnetic torque, making the motor rotate to drive the load.
Application
Industrial:
Industrial Controls
Exercise & Health: Treadmill
Optional parts

Warm reminder:
The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact marketing@leiligroup.com.
Availability:
Quantity:

PDF Export

  • Sports health

  • 120+

  • 0-0.1, 0.1-0.2, 0.2-0.3, More Than 0.3

  • 10+

Performance parameter



Motor type

Voltage

   (V)

kv value

   (V)

No-load current

         (A)

Rated output power

              (W)

Electric current

         (A)

Rated torque

     (N.m)

Efficiency Insulation class Weight (kg)
116ZY1-1 130 28.4 ≤2.0 3170 29.6 8.2 82.10% N 14
116ZY1-2

130

28.4 ≤2.0 3170 29.6 8.2 82.10% 15
116ZY2-1

130

26.5 ≤1.75 2268 21.2 5.4 80.91% 10
116ZY3-1

130

26.5 ≤1.75 2865 24.5 6.3 84.10% 13


Mechanical dimension


116ZY Treadmill Motor
