30BYJ46 Geared Stepper Motor

█ Product Introduction

Model:30BYJ46
The rotor of Leili permanent magnet stepping motor (BYJ series stepping motor) is made of permanent magnet material, and the number of poles of the rotor is the same with that of the stator. It is characterized by good dynamic performance and large output torque
█ Application
Home appliances: air conditioner, refrigerator, electric fan

█ Optional parts

Shaft length, frame

Warm reminder:
The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact marketing@leiligroup.com.

Availability:

Quantity:



Inquiry PDF Export

Application:
Home appliance
Dimension Diameter（Geared Stepper Motor）:
30
Step Angle(°) Geared Stepper Motor:
7.5
Rated Voltage（DCV）Geared Stepper Motor:
12
Resistance(Ω) Geared Stepper Motor:
101-200
Operating Frequency (Geared Stepper Motor):
100
Pull in Torque(mN.m) Geared Stepper Motor:
1-100

Product Description

Performance parameter

model	voltage V	resistance (Ω)	freq (PPS)	pull-in torque (mN.m)	torque (mN.m)	pull-in freq (PPS)	pull-out freq (PPS)	temp K	noise dB(A)	stepping angle （1-2phase）
30BYJ46	12	100	100	≥98	≥78.4	≥350	≥800	≤50	≤40	7.5°/85.25
	12	130	100	≥78.4	≥39.2	≥350	≥800	≤50	≤40
	12	200	100	≥58.8	≥39.2	≥350	≥600	≤50	≤40
