42BYJ46 Geared Stepper Motor

█ Product Introduction

Model:42BYJ46
The rotor of Leili permanent magnet stepping motor (BYJ series stepping motor) is made of permanent magnet material, and the number of poles of the rotor is the same with that of the stator. It is characterized by good dynamic performance and large output torque
█ Application
Home appliances: air conditioners

█ Optional parts

Shaft length, frame

Warm reminder:
The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact marketing@leiligroup.com.

Availability:

Quantity:



Inquiry PDF Export

Application:
Home appliance
Dimension Diameter（Geared Stepper Motor）:
42
Step Angle(°) Geared Stepper Motor:
7.5
Rated Voltage（DCV）Geared Stepper Motor:
12
Resistance(Ω) Geared Stepper Motor:
0-100
Operating Frequency (Geared Stepper Motor):
100, 250
Pull in Torque(mN.m) Geared Stepper Motor:
1-100, 101-200, 201-300, 301-400, 401-500, 500+

Product Description

Performance parameter

Motor type	Voltage	Resistance	Frequency	Pull in torque	Self-positioning torque	No-load pull-in frequency	No-load pull-out frequency	Temperature rise	Noise	Step Angle	Insulation class
Motor type	V	(Ω)	(PPS)	(mN.m)	(mN.m)	(PPS)	(PPS)	K	(A)	（1-2phase）	Insulation class
42BYJ46	12	40	250	≥78.4	≥49	≥300	≥350	≤90	≤40	7.5°/22.7	E
	12	50	100	≥150	≥100	≥200	≥200	≤90	≤40	7.5°/33.3
	12	85	100	≥150	≥100	≥200	≥200	≤90	≤40	7.5°/40
	12	80	100	≥294	≥100	≥300	≥350	≤90	≤40	7.5°/100
