Product Parameter
| Motor type | Rated voltage (VDC) | Power (W) | Electric current (A) | Service voltage range (V) | Rotational speed (Max) (RPM) | Lift (m) | Flow rate (LPM) | Class of protection | L Size (mm) | W Size (mm) | Coil | Magnet (mA) |
| BLP43-x | 24 | 200 | 8.5 | 18-32 | 5700 | ≥ 10m | max: 100 | IP67 | 114 | Ø89 | Cu | Neodymium iron boron |
| BLP43-y | 24 | 100 | 4.2 | 18-32 | 5700 | ≥ 10m | max: 60 | IP67 | 104 | Ø89 | Cu | Neodymium iron boron |
| BLP43-z | 24 | 60 | 2.5 | 18-32 | 5000 | ≥ 8m | max: 30 | IP67 | 102 | Ø71 | Cu | Neodymium iron boron |
Mechanical dimension
Product Parameter
| Motor type | Rated voltage (VDC) | Power (W) | Electric current (A) | Service voltage range (V) | Rotational speed (Max) (RPM) | Lift (m) | Flow rate (LPM) | Class of protection | L Size (mm) | W Size (mm) | Coil | Magnet (mA) |
| BLP43-x | 24 | 200 | 8.5 | 18-32 | 5700 | ≥ 10m | max: 100 | IP67 | 114 | Ø89 | Cu | Neodymium iron boron |
| BLP43-y | 24 | 100 | 4.2 | 18-32 | 5700 | ≥ 10m | max: 60 | IP67 | 104 | Ø89 | Cu | Neodymium iron boron |
| BLP43-z | 24 | 60 | 2.5 | 18-32 | 5000 | ≥ 8m | max: 30 | IP67 | 102 | Ø71 | Cu | Neodymium iron boron |
Mechanical dimension
