Linear push rod motor ZXJ1-28

█ Product Introduction

█ Applications
Cooker hood

█ Optional parts

Warm reminder:
The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact marketing@leiligroup.com.

Availability:

Quantity:


Inquiry PDF Export

Application:
Home appliance
Dimension Diameter（Geared Stepper Motor）:
20
Step Angle(°) Geared Stepper Motor:
3.75
Rated Voltage（DCV）Geared Stepper Motor:
5
Resistance(Ω) Geared Stepper Motor:
0-100
Operating Frequency (Geared Stepper Motor):
100
Pull in Torque(mN.m) Geared Stepper Motor:
1-100

Product Description

Performance Parameter

Model	Voltage (DC.V)	Lnput Current (A)	Operating Stroke (mm)	Working time (no load) (s)	Rated Load (N)	Rated Current (mA)	Working time (rated load) (s)	Stall Current (A)
ZXJ1-28	12	15A	71±1	6±1	60	5	910±2	<1
