PM Stepping Motor 20BY46

Product Introduction
Model:20BY46
The rotor of the Leili PM stepping motor uses permanent magnetic materials. The PM stepping motor’s continuous operation follows the principle that the same poles repel and different poles attract between the rotor and the stator. It is generally an inner rotor type motor, and the N and S poles are evenly distributed on the outer surface of the cylindrical rotor (The outer surface is toothless). PM stepping motors are usually two-phase, with small torque and volume.
Application
Industry: Printer
Optional parts

Warm reminder:
The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact marketing@leiligroup.com.

Availability:
Quantity:

PDF Export

  • Industry

  • 20

  • 15

  • 12

  • 0-30

  • 0-50

Performance parameter


motor model Step angle Excitation method Drive way Voltage Current / phase Coil resistance / phase Self-positioning torque Self-positioning torque Holding torque noise Working temperature
(°) (VDC) (mA) (Ω) (mN.m) (mN·m) (Ω) (A) (℃)
20BY46 15 2-2 Bipolar 12 - 30 2.94 ≥ 9.8 AC 500 [V] ≤ 50 -10 ~ 50
Phase Bipolar 1 [min] (No strange sound)


Mechanical dimension


PM Stepping Motor 20BY46
