RS-548SH DC Brush Motor

█ Product Introduction
Model:RS-548SH
A brushed DC motor is a DC motor, assembling main magnetic pole and brush on the stator and assembling the winding coil and commutator assembled on the rotor. The electric energy from the dc power supply enters the armature winding through the brush and commutator, generating the armature current. The magnetic field generated by the armature current interacts with the main magnetic field to generate the electromagnetic torque, making the motor rotate to drive the load.
█ Application
Automobile: Automobile throttle valve
█ Optional parts

Warm reminder:
The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact marketing@leiligroup.com.
Availability:
Quantity:
Inquiry

PDF Export

  • Home appliance

  • 20

  • 3.75

  • 5

  • 0-100

  • 100

  • 1-100

Performance parameter


model vol no-load max stall
working range
(V)		 rated
(V)		 speed
(r/min)		 current
(A)		 speed
(r/min)		 current
(A)		 torque
(mN.m)		 torque
(g.cm)		 output
(W)		 torque
(mN.m)		 torque
(g.cm)		 current
(A)
RS-548SH 6.5-16 13.5 6100 0.55 4764 1.96 35 357.143 17.476 160 1632.65 7.00


Mechanical dimension


RS-548SH DC Brush Motor


 Performance Curves


RS-548SH DC Brush Motor2
