RS-775SH DC Brush Motor

Product Introduction
Model:RS-775SH
A brushed DC motor is a DC motor, assembling main magnetic pole and brush on the stator and assembling the winding coil and commutator assembled on the rotor. The electric energy from the dc power supply enters the armature winding through the brush and commutator, generating the armature current. The magnetic field generated by the armature current interacts with the main magnetic field to generate the electromagnetic torque, making the motor rotate to drive the load.
Application
Appliance: Water purifier
Optional parts

Warm reminder:
The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact marketing@leiligroup.com.
Availability:
Quantity:

PDF Export

  • Home appliance

  • 0-30

  • 3000-10000

  • More Than 0.3

  • 5-10

  • 10+

Performance parameter



Motor type
Voltage
  Unloaded
      At maximum efficiency
     Locked-rotor
Scope of work (V)

Rated

 (V)

Speed
(r/min)
Electric current (A) Speed
(r/min)
Electric current (A) Torque (mN.m) Torque (g.cm) Exportation      (W) Torque (mN.m) Torque (g.cm)

Electric current

   (A)

RS-775SH 3159 6-25 12 3300 0.315 2713 1.40 38.60 393.9 11 208.24 2124.9 6.10
RS-775SH 2783 6-30 24 4300 0.20 3550 0.93 49.00 500 18.217 281.1 2868.367 4.48


Mechanical dimension


RS-775SH DC Brush Motor

 Performance Curves


RS-775SH DC Brush Motor2
